MSI Mag A650GL

Free Shipping

We provide free worldwide delivery on all orders - no minimum spend required.

30-Day Easy Returns

You can return or exchange any unused item in its original packaging within 30 days of delivery.

The MSI Mag A650GL offers a practical fan solution for household use according to the supplied operating specifications.

Key Features

Product type: Fan
Brand: MSI
Category: Power Supplies

Compatibility: Review the listed power, capacity, operating mode and room-use information to make sure the appliance suits the intended environment.

Specifications
80 PLUS certification	80 PLUS Bronze
AC input voltage	100 - 240 V
ATX power connector (20+4 pin)	Yes
ATX Power connector (24-pin)	No
Cabling type	Fully-Modular
Combined power (+12V)	648 W
Combined power (+3.3V)	100 W
Combined power (+5V)	100 W
Combined power (+5Vsb)	12.5 W
Combined power (-12V)	3.6 W
Cooling type	Active
CPU power connector (4+4 pin)	Yes
Depth	140 mm
Efficiency	90%
EPS power connector (4+4 pin)	Yes
EPS power connector (8-pin)	No
Fan diameter	12 cm
Floppy disk drive connector	No
Harmonized System (HS) code	84733020
Height	86 mm
Illumination	No
Max output current (+12V)	54 A
Max output current (+3.3V)	20 A
Max output current (+5V)	20 A
Max output current (+5Vsb)	20 A
Max output current (-12V)	0.3 A
Maximum input current (@110V)	10 A
Maximum input current (@220V)	5 A
Motherboard power connector	20+4 pin ATX
Number of fans	1 fan(s)
Number of SATA power connectors	6
On/off switch	Yes
PCI Express connector	Yes
PCI Express power connectors (12+4 pin)	0
PCI Express power connectors (12-pin)	0
PCI Express power connectors (6+2 pin)	4
PCI Express power connectors (6-pin)	0
PCI Express power connectors (8-pin)	0
Peripheral (Molex) power connectors (4-pin)	4
Power Factor Correction (PFC) type	Active
Power protection features	Over current, Over power, Over voltage, Short circuit
Power supply unit (PSU) form factor	ATX
Product colour	Black
Purpose	PC
Total power	650 W
Width	150 mm
