TP-Link 28 Port Easy Smart Switch

TP-Link 28 Port Easy Smart Switch
TP-Link 28 Port Easy Smart Switch
TP-Link 28 Port Easy Smart Switch
TP-Link 28 Port Easy Smart Switch
TP-Link 28 Port Easy Smart Switch
TP-Link 28 Port Easy Smart Switch
TP-Link 28 Port Easy Smart Switch
TP-Link 28 Port Easy Smart Switch
TP-Link 28 Port Easy Smart Switch
TP-Link 28 Port Easy Smart Switch
TP-Link 28 Port Easy Smart Switch
  • Stock: In Stock
  • Brand: TP-Link
  • Model: TLSG1428PE
  • EAN: 840460604161
$317.17
Ex Tax: $317.17
Free Shipping
We provide free worldwide delivery on all orders - no minimum spend required.
30-Day Easy Returns
You can return or exchange any unused item in its original packaging within 30 days of delivery.

Designed for compatible wired or wireless network deployments, the TP-Link 28 Port Easy Smart Switch provides a network switch option from TP-Link. The supplied specifications list power as 250W.

Key Features

  • 28-Port Gigabit Easy Smart Switch with 24-Port PoE+
  • 24 10/100/1000Mbps RJ45 PoE+ Ports Switch with 2 SFP Slots
  • PoE power budget is up to 250W
  • Compatible with PoE devices and non-PoE wired devices

Technical Details

  • Power: 250W
  • Data Rate: 1000Mbps
  • Connections / Standards: RJ45, SFP, PoE+, PoE

Compatibility: Check the listed compatibility before ordering. The supplied product data identifies compatibility with PoE devices and non-PoE wired devices.

Specifications
10G supportNo
AC input frequency50 - 60 Hz
AC input voltage100 - 240 V
Auto MDI/MDI-XYes
Auto-negotiationYes
Basic switching RJ-45 Ethernet ports quantity26
Basic switching RJ-45 Ethernet ports typeGigabit Ethernet (10/100/1000)
Broadcast storm controlYes
Cable types supportedCat3, Cat4, Cat5, Cat5e, Cat6
Cables includedAC
CertificationCE, FCC, RoHS
Copper ethernet cabling technology10BASE-T, 100BASE-TX, 1000BASE-T
Depth220 mm
Fiber ethernet cabling technology1000BASE-X
Flow control supportYes
Form factor1U
Forwarding rate41.7 Mpps
Gigabit Ethernet (copper) ports quantity26
Harmonized System (HS) code85176990
Height44 mm
IGMP snoopingYes
Jumbo frames10000
Jumbo frames supportYes
Link aggregationYes
MAC address table8000 entries
Multicast supportYes
Networking standardsIEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Number of fans2 fan(s)
Number of queues4
Number of VLANs32
Operating relative humidity (H-H)10 - 90%
Operating temperature (T-T)0 - 50 °C
Package depth528 mm
Package height100 mm
Package weight2.29 kg
Package width336 mm
Packet buffer memory4.1 MB
Port mirroringYes
Power consumption (max)1039.03 W
Power over Ethernet (PoE)Yes
Power over Ethernet (PoE) power per port30 W
Power over Ethernet plus (PoE+) ports quantity24
Power sourceAC
Power supply includedYes
Product colourBlack
Quality of Service (QoS) supportYes
Rack mount kitYes
Rack mountingYes
Rate limitingYes
Security algorithmsSNMP, SNMPv2, SNMPv3
SFP module slots quantity2
Storage relative humidity (H-H)5 - 90%
Storage temperature (T-T)-40 - 70 °C
Store-and-forwardYes
Switch layerL2
Switch typeManaged
Switching capacity56 Gbit/s
Total Power over Ethernet (PoE) budget250 W
User guideYes
Virtual LAN featuresPort-based VLAN, Tagged VLAN
VLAN supportYes
Web-based managementYes
Width440 mm
